Newcon Optik SENTINEL 9Hz High Resolution Thermal Rangefinder Binocular, Waterproof (LRF 640)

The SENTINEL (640) utilizes a large diameter Germanium lens to extend its observation range beyond 2,500m. The SENTINEL (640) is an advanced thermal imaging binocular with a wide variety of tactical, law enforcement, border security and special forces applications. The SENTINEL (640) utilizes a high resolution uncooled thermal sensor to perceive differences in the thermal signature of objects within the field of view.

This device can detect objects at remote distances 24 hours a day, through smoke, fog or camouflage. This device does not produce any audible sounds while in operation.

Features

Ergonomic design

High-resolution uncooled thermal sensor

Superb image clarity

640 resolution variant

Simple to operate

Specifications

Sensor
Resolution (pixels)	640×480
Sensitivity (mK @F1.0)	<40
Operating wavelength (µ)	8-14
Video Output	PAL
DRI range (m)
Human	2,500/625/313
Tank	6,800/1,700/850
Optics
Objective focal length (mm)	75
Field of view (°)	8.3×6.2
Eye relief (mm)	25
Dioptric correction	-6 to +
Zoom	Fixed 2x, 3x, 4x, plus continuous zoom
Mechanics, Electronics & Environmental
Dimensions (mm)	208x89x146
Weight without batteries (g)	1030
Battery type	6x AA
Battery life (hours)	8
Operating Temperature (°C)	-40 to +50
Waterproofing		MIL-STD-810G
Laser Rangefinder
Laser wavelength (nm)		1550
Measurement distance to 2.3×2.3m NATO (m)		3,000
Distance measuring accuracy (m)		±1
Device measurement capability (m)		5,000
Azimuth measuring range (°)		360
Elevation measuring range (°)		±60
